Compact and Special Port Aligners

  • System Flexibility: Enables axis alignment between flanges.
  • Adapted Design: Different designs are available for a wide range of applications.

  • Specialized Design

    Some ultra-high vacuum (UHV) systems have special requirements when it comes to the alignment of system components.

    A number of specialized port aligner designs are available, such as more compact designs for applications with tight size constraints.

    Port aligners are designed to be adjusted as a system or workflow is being established or tested.
    For more situational positioning of system components, we recommend using a Ferrovac Boomerax Multiaxis Manipulator instead:

    X/Y/Z/R Manipulators

    Available Options

    • Extra Compact Port Aligner: This design offers a shorter insertion length for application with tighter dimsenional constraints and less displacement requirements.
    • Gas Spring Loaded Port Aligner: Specialized design that can be outfitted with gas loaded springs, nullifying the pull of the vacuum-to-atmosphere pressure difference.
    • Custom Design: We will gladly consider working with you to create a custom design for your specific application.

    Connect with an Expert

    Product Code

    Viewing enlarged image:

    Flange Size:

    Port aligners are available in a wide range of standard conflat flange sizes.
    Depending on the port aligner design, different size ranges may be available.

    Options:

    Besides the standard port aligner design, a number of different port alignment solutions are available, for a wide range of applications.
